FPC板基本组成培训资料.ppt
原材料及FPC基本组成培训教材,一、铜箔基材的组成：1、单面板铜箔基材的组成：铜箔+胶+PI 2、单面板铜箔基材的叠构：,3、双面板铜箔基材的组成：铜箔+胶+PI+胶+铜箔 4、双面铜箔基材的叠构：,二、保护膜的组成：1、保护膜的组成：胶+PI 2、保护的叠构：,三、基本单位换算：1mil=0.0254mm 1OZ 1.4mil 1inch=25.4mm 1inch=103mil,四、FPC基本组成及叠构厚度：（以下列几种型号 基材为例）单面铜箔基材型号：XSIR050513 组成厚度：0.5mil(PI)+0.5mil(胶)+0.5OZ（铜箔）双面铜箔基材型号：NDIR101020NOC 组成厚度：1OZ(铜箔)+0.8mil(胶)+1mil(PI)+0.8mil(胶)+1OZ（铜箔）保护膜型号：FD0515HL 组成厚度：0.5mil(PI)+0.6mil(胶)保护膜型号：CA231 组成厚度：0.5mil(PI)+0.5mil(胶),1、单面板的叠构组成：a、单面板组成：铜箔基材+保护膜 b、单面板叠构：,c、单面板厚度公差：0.5mil(PI)+0.5mil(胶)+0.5OZ（铜箔）+0.5mil(PI)+0.6mil(胶)=2.8mil（0.0710.01 mm）0.5mil(PI)+0.5mil(胶)+0.5OZ（铜箔）+0.5mil(PI)+0.5mil(胶)=2.7mil（0.0690.01 mm）,2、双面板的叠构组成：a、双面板组成：保护膜+铜箔基材+保护膜 b、双面板叠构：,c、双面板厚度公差：0.5mil(PI)+0.6mil(胶)+1OZ（铜箔）+0.8mil(胶)+1mil(PI)+0.8mil(胶)+1OZ（铜箔）+0.5mil(PI)+0.6mil(胶)=7.6mil(0.1930.02mm)0.5mil(PI)+0.5mil(胶)+1OZ（铜箔）+0.8mil(胶)+1mil(PI)+0.8mil(胶)+1OZ（铜箔）+0.5mil(PI)+0.5mil(胶)=7.4mil(0.1880.02mm),3、镂空板的叠构组成：a、镂空板的组成：保护膜+1OZ纯铜箔+保护膜 b、镂空板的叠构,c、镂空板厚度公差：0.5mil(PI)+0.6mil(胶)+1OZ（纯铜箔）+0.5mil(PI)+0.6mil(胶)=3.6mil(0.0910.02mm)0.5mil(PI)+0.5mil(胶)+1OZ（纯铜箔）+0.5mil(PI)+0.5mil(胶)=3.4mil(0.0860.02mm),4、双层板的叠构组成：a、双层板组成：保护膜+铜箔基材+纯胶+铜箔基材+保护膜 b、双层板叠构：,c、双层板厚度公差：0.5mil(PI)+0.6mil(胶)+0.5mil(PI)+0.5mil(胶)+0.5OZ（铜箔）+0.5mil(胶)+0.5mil(PI)+0.5mil(胶)+0.5OZ（铜箔）+0.5mil(PI)+0.6mil(胶)=6.1mil(0.1550.02mm)0.5mil(PI)+0.5mil(胶)+0.5mil(PI)+0.5mil(胶)+0.5OZ（铜箔）+0.5mil(胶)+0.5mil(PI)+0.5mil(胶)+0.5OZ（铜箔）+0.5mil(PI)+0.5mil(胶)=5.9mil（0.1500.02mm),5、三层板的叠构组成：a、三层板组成：保护膜+铜箔基材+纯胶+保护膜+铜箔基材+纯胶+铜箔基材+保护膜 b、三层板叠构：,c、三层板厚度公差：0.5mil(PI)+0.6mil(胶)+0.5OZ（铜箔）+0.5mil(胶)+0.5mil(PI)+0.5mil(胶)+0.5mil(PI)+0.6mil(胶)+0.5OZ（铜箔）+0.5mil(胶)+0.5mil(PI)+0.5mil(胶)+0.5mil(PI)+0.5mil(胶)+0.5OZ（铜箔）+0.6mil(胶)+0.5mil(PI)=9.4mil(0.2390.03mm)0.5mil(PI)+0.5mil(胶)+0.5OZ（铜箔）+0.5mil(胶)+0.5mil(PI)+0.5mil(胶)+0.5mil(PI)+0.5mil(胶)+0.5OZ（铜箔）+0.5mil(胶)+0.5mil(PI)+0.5mil(胶)+0.5mil(PI)+0.5mil(胶)+0.5OZ（铜箔）+0.5mil(胶)+0.5mil(PI)=9.1mil(0.2310.03mm),6、四层板的叠构组成：a、四层板组成：保护膜+铜箔基材+纯胶+保护膜+铜箔基材+纯胶+铜箔基 材+保护膜+纯胶+铜箔基材+保护膜 b、四层板叠构：,c、四层板厚度公差：0.5mil(PI)+0.6mil(胶)+0.5OZ（铜箔）+0.5mil(胶)+0.5mil(PI)+0.5mil(胶)+0.5mil(PI)+0.6mil(胶)+0.5OZ（铜箔）+0.5mil(胶)+0.5mil(PI)+0.5mil(胶)+0.5mil(PI)+0.5mil(胶)+0.5OZ（铜箔）+0.6mil(胶)+0.5mil(PI)+0.5mil(胶)+0.5mil(PI)+0.5mil(胶)+0.5OZ（铜箔）+0.6mil(胶)+0.5mil(PI)=12.7mil(0.3230.04mm)0.5mil(PI)+0.5mil(胶)+0.5OZ（铜箔）+0.5mil(胶)+0.5mil(PI)+0.5mil(胶)+0.5mil(PI)+0.5mil(胶)+0.5OZ（铜箔）+0.5mil(胶)+0.5mil(PI)+0.5mil(胶)+0.5mil(PI)+0.5mil(胶)+0.5OZ（铜箔）+0.5mil(胶)+0.5mil(PI)+0.5mil(胶)+0.5mil(PI)+0.5mil(胶)+0.5OZ（铜箔）+0.5mil(胶)+0.5mil(PI)=12.3mil(0.3120.04mm),谢谢结束,
